Black Box FlexPoint Modular Media Converter, RS-232 to Fiber, Single-Mode, 30 km, SC - 1 x SC Ports - Rack-mountable, Wall Mountable, Desktop - TAA Compliant
1 x SC Ports - Rack-mountable, Wall Mountable, Desktop - TAA Compliant
| Fiber Mode Supported | Single-mode |
| Maximum Distance Supported | 18.64 Mile |
| Number of SC Ports | 1 |
| Additional Information | Product works with:
FlexPoint 14-Port Power Chassis (LMC200) FlexPoint 5-Position Mounting Kit (LMC205) Questions? Contact our FREE Tech Support. |
| Brand Name | Black Box |
| Certifications & Standards | - CE
- FCC Class A Part 15
- UL 81J1 E81356
- CSA Canada UL LR99169
|
| Compatibility | Black Box FlexPoint Media Converter Chassis |
| Country of origin | United States |
| Depth | 4" |
| Environmental Certification | WEEE |
| Environmental Certification | RoHS |
| Environmentally Friendly | Yes |
| Form factor | Wall Mountable |
| Form factor | Desktop |
| Form factor | Rack-mountable |
| Height | 1" |
| Limited Warranty | 2 Year |
| Manufacturer | Black Box Corporation |
| Manufacturer Part Number | ME662A-SSC |
| Manufacturer Website Address | http://www.blackbox.com |
| Marketing Information | - Autosenses speeds up to 115.2 kbps.
- Works as a standalone or hot-swappable chassis-based extender.
- Easy to install.
- Includes a power supply. Or you can power multiple units with the space-saving 19" rackmountable FlexPoint Power Chassis.
- Features DTE/DCE configuration for easy connections to DTE or DCE devices using straight-through cabling.
- Supports half- and full-duplex.
- Remote loop capability for remote fiber testing and LEDs for status monitoring.
Extend async RS232 devices beyond the 50 ft limitation using single-mode fiber cables at data rates up to 115.2 kbps and reach distances of 18.6 MI. (30KM). Serial extenders work well in factory automation building automation and process automation where PLC's with RS232 interfaces are used to control devices. The ability to extend the distance to their devices over single-mode fiber while also adding protection from electrical interference which can be caused by large motors which are prevalent in these environments is very beneficial.
|
| Media Type Supported | Optical Fiber |
| Package Contents | - FlexPoint Modular Media Converter RS-232 to Fiber Single-Mode 30 km SC
- DC Power Supply
|
| Product Line | FlexPoint |
| Product Name | FlexPoint Modular Media Converter RS-232 to Fiber Single-Mode 30 km SC |
| Product Type | Transceiver/Media Converter |
| Total Number of Ports | 2 |
| UPC Alternates | 013269144040 093007270613 650361664535 822088079033 |
| USB | No |
| Weight (Approximate) | 6.40 oz |
| Width | 3" |
