Tripp Lite HDMI Over Cat5/6 Active Video Extender Kit Transmitter Receiver 1080p 200' - 2 Input Device - 2 Output Device - 150 ft Range - 2 x Network (RJ-45) - 1 x HDMI In - 2 x HDMI Out - Twisted Pair - Category 6 - Rack-mountable, Wall Mountable - TAA Compliant
2 Input Device - 2 Output Device - 150 ft Range - 2 x Network (RJ-45) - 1 x HDMI In - 2 x HDMI Out - Twisted Pair - Category 6 - Rack-mountable, Wall Mountable - TAA Compliant
| Brand Name | Tripp Lite |
| Certifications & Standards | |
| Connectivity technology | Wired |
| Country of origin | Taiwan |
| Environmental Certification | RoHS |
| Environmentally Friendly | Yes |
| Form factor | Rack-mountable |
| Form factor | Wall Mountable |
| Limited Warranty | 1 Year |
| Manufacturer | Tripp Lite by Eaton |
| Manufacturer Part Number | B126-1A1 |
| Manufacturer Website Address | http://www.tripplite.com |
| Marketing Information | The B126-1A1 transmits a 1080p (60Hz) signal to a monitor up to 150 ft. away using Cat5e/6 cable. To achieve maximum distance and resolution use 24Awg Solid Wire Cat5e/6 cable. (Tripp Lite's N202-Series) The transmitter unit features an HDMI port for the connection of a local monitor. The receiver unit features a built-in Equalization control for adjustment of the video image. Supports 24-bit True Color (8-bits per channel) HDCP 3D and both stereo audio and 7.1 channel surround sound audio (7.1 channel surround sound signal will be Multi-Channel or PCM). Installation is simple. Connect the transmitter unit to an HDMI source using a Tripp Lite P568-Series HDMI cable (not included). Connect the receiver unit to a display using a Tripp Lite P568-Series HDMI cable (not included). Finally connected the receiver to the RJ45 port on the transmitter using a single Cat5e/6 cable. Compliant with the Federal Trade Agreements Act (TAA) for GSA Schedule purchases. |
| Maximum Operating Distance | 150 ft |
| Media Type Supported | Twisted Pair |
| Number of HDMI Inputs | 1 |
| Number of Network (RJ-45) Ports | 2 |
| Package Contents | - B126-1A1 Video Extender/Console
- Screwdriver for Adjustment of Equalization
- 2 x Mounting Hardware
- 2 x External Power Supply
- Owner's manual
|
| Product color | Black |
| Product Name | B126-1A1 Video Extender/Console |
| Product Type | Video Extender Transmitter/Receiver |
| Twisted Pair Cable Standard | Category 6 |
| UPC Alternates | 037332158925 373321589258 818240567210 971478257701 993245658788 993247735579 |
