EVGA 750W Gold Switching Power Supply - Internal - 120 V AC, 230 V AC Input - 3.3 V DC @ 24 A, 5 V DC @ 24 A, 12 V DC @ 62.5 A, -12VDC @ 0.5A, 5 V DC @ 3 A Output - 750 W - 1 +12V Rails - 1 Fan(s) - ATI CrossFire Supported - NVIDIA SLI Supported - 92% Efficiency
Internal - 120 V AC, 230 V AC Input - 3.3 V DC @ 24 A, 5 V DC @ 24 A, 12 V DC @ 62.5 A, -12VDC @ 0.5A, 5 V DC @ 3 A Output - 750 W - 1 +12V Rails - 1 Fan(s) - ATI CrossFire Supported - NVIDIA SLI Supported - 92% Efficiency
Specification Compliance | ATX |
Brand Name | EVGA |
Country of origin | Taiwan |
Efficiency | 92% |
Environmental Certification | WEEE |
Environmental Certification | 80 Plus Gold |
Environmental Certification | ErP Lot 3 |
Environmental Certification | RoHS |
Environmentally Friendly | Yes |
Form factor | Internal |
Height | 3.4" |
Input voltage | 120 V AC |
Input voltage | 230 V AC |
Limited Warranty | 10 Year |
Manufacturer | EVGA Corporation |
Manufacturer Part Number | 220-G6-0750-X1 |
Manufacturer Website Address | http://www.evga.com |
Marketing Information | The EVGA SuperNOVA G6 power supplies feature a new platform design using new materials and better layout placement to achieve greater performance with extremely low ripple and noise in an even smaller chassis. With a full-bridge LLC Resonant Rectification and DC-DC design the SuperNOVA G6 provides rock-solid stability relentless efficiency and extremely tight voltage regulation. |
Number of Fans | 1 |
Output power | 750 W |
Output voltage | 5 V DC @ 24 A |
Output voltage | 3.3 V DC @ 24 A |
Output voltage | 5 V DC @ 3 A |
Output voltage | 12 V DC @ 62.5 A |
Output voltage | -12VDC @ 0.5A |
Product Line | SuperNOVA |
Product Model | 750 G6 |
Product Name | 750W Gold Switching Power Supply |
Product Type | Power Supply |
UPC Alternates | 843368068318 |
Weight (Approximate) | 7 lb |
Width | 5.9" |
