Asus Strix Z690-A Desktop Motherboard - Intel Z690 Chipset - Socket LGA-1700 - Intel Optane Memory Ready - ATX - Pentium Gold, Celeron, Core i5, Core i7, Core i9 Processor Supported - 128 GB DDR5 SDRAM Maximum RAM - DIMM, UDIMM - 4 x Memory Slots - HDMI - DisplayPort - 4 x SATA Interfaces
Pentium Gold, Celeron, Core i5, Core i7, Core i9 Processor Supported - 128 GB DDR5 SDRAM Maximum RAM - DIMM, UDIMM - 4 x Memory Slots - HDMI - DisplayPort - 4 x SATA Interfaces
| Chipset Manufacturer | Intel |
| Chipset Model | Z690 |
| Maximum Memory Supported | 128 GB |
| Memory Speed Supported | 5200 MHz |
| Memory Speed Supported | 5000 MHz |
| Memory Speed Supported | 4800 MHz |
| Memory Speed Supported | 6000 MHz |
| Memory Speed Supported | 5800 MHz |
| Memory Speed Supported | 5400 MHz |
| Memory Speed Supported | 5600 MHz |
| Number of Memory Slots | 4 |
| Number of Onboard USB 3.2 Ports | 3 |
| Number of PCI Express x1 Slots | 2 |
| Onboard Video | CPU Dependent Video |
| Processor Generation Supported | 12th Gen |
| Processor Socket | Socket LGA-1700 |
| Processor Supported | Pentium Gold |
| Processor Supported | Core i9 |
| Processor Supported | Celeron |
| Processor Supported | Core i5 |
| Processor Supported | Core i7 |
| S/PDIF | Yes |
| Total Number of Onboard USB Ports | 7 |
| Audio Channels | 7.1 |
| Brand Name | Asus |
| Controller Type | Serial ATA/600 |
| Depth | 9.6" |
| Environmental Certification | RoHS |
| Form factor | ATX |
| Limited Warranty | 3 Year |
| Manufacturer | ASUS Computer International |
| Manufacturer Part Number | PRIME Z690-A |
| Manufacturer Website Address | http://usa.asus.com |
| Marketing Information | Intel® Z690 (LGA 1700) ATX motherboard with PCIe® 5.0 four M.2 slots 16+1 DrMOS power stages DDR5 HDMI® DisplayPort™ Intel 2.5 Gb Ethernet USB 3.2 Gen 2x2 Type-C® front USB 3.2 Gen 2 Type-C® Thunderbolt™ 4 support and Aura Sync RGB lighting - Intel® LGA 1700 socket: Ready for 12th Gen Intel processors
- Enhanced power solution: 16+1 DrMOS ProCool sockets alloy chokes and durable capacitors for stable power delivery
- AI Overclocking: Optimizes performance based on CPU and cooler loads to achieve results that are extremely close to manual tuning by experts
- AI Cooling: Manages and controls all motherboard fans automatically optimizing settings based on current system load and temperature
- Two-Way AI Noise-Cancelation: Reduces background noise from the microphone and audio output for crystal-clear communication in games or video conferences
- Comprehensive cooling: Large VRM heatsinks M.2 heatsinks M.2 backplate with Q-Latch hybrid fan headers and Fan Xpert 4
- Next-gen connectivity: DDR5 memory PCIe® 5.0 Intel 2.5 Gb Ethernet USB 3.2 Gen2x2 Type-C® front panel USB 3.2 Gen 2 Type-C® Thunderbolt™ 4 header support 4 PCIe® 4.0 M.2
PRIME
ASUS Prime series motherboards are expertly engineered to unleash the full potential of 12th Generation Intel® processors. Boasting a robust power design comprehensive cooling solutions and intelligent tuning options Prime Z690-A provides users and PC DIY builders a range of performance tuning options via intuitive software and firmware features.
ASUS Prime Z690-A offers a sleek futuristic-looking build with a black and white finish space-shuttle-inspired design elements metallic nameplate and PCB cover. FLEXIBILITY
Comprehensive controls form the foundation of the ASUS Prime series. The Prime Z690 motherboard packs flexible tools to tune every aspect of your system enabling performance tweaks to perfectly match the way you work to maximize productivity. 5-Way Opitmization
ASUS 5-Way Optimization makes your PC smart. Along with taking care of complex tuning and dynamically optimizing essential aspects of your system it provides overclocking profiles that are tailored for your rig. - Easy Optimization is an automated tuning utility that enhances overclocking and cooling profiles for your unique system configuration.
- A stress test feature allows you to optimize and overclock for CPU- or memory-centric workloads.
CPU Performance Boost
The TurboV Processing Unit (TPU) is an intelligent system-tuning utility that automatically fine-tunes voltages monitors system stats and adjusts overclocking parameters for optimal performance. All-Around Energy Efficiency
The Energy Processing Unit (EPU) automatically optimizes power consumption and maximizes energy savings with Away mode - a smart setting that creates an extreme energy-saving scenario by shutting down unused I/O controllers. Precise Digital Power Control
The Digi+ voltage-regulator module (VRM) delivers real-time control over voltage droop automatically switching frequency and power-efficiency settings. It also allows you to fine-tune your CPU for ultimate stability and performance. App-Specific Optimization
Turbo App allows you to define CPU overclocking apply fan profiles prioritize network data and optimize audio settings at the app level so your system is set up exactly as needed. |
| Memory form factor | DIMM |
| Memory form factor | UDIMM |
| Memory Technology | DDR5 SDRAM |
| Package Contents | - Prime Z690-A Desktop Motherboard
- 2 x SATA 6Gb/s cables
- 1 x M.2 Rubber Package(s)
- 1 x Q-connector
- 1 x M.2 Q-Latch package(s)
- 1 x Support DVD
- 1 x User Guide
|
| Product Line | Strix |
| Product Model | Z690-A |
| Product Name | Prime Z690-A Desktop Motherboard |
| Product Type | Desktop Motherboard |
| RAID Levels | 0 |
| RAID Levels | 5 |
| RAID Levels | 10 |
| RAID Levels | 1 |
| Total Number of USB Ports | 8 |
| UPC Alternates | 195553447324 |
| Width | 12" |
